Electro-Voice EVF-1122D/94-WHT - 12” 2-Way Loudspeaker with 90 x 40 Coverage, EVCoat White

The Electro-Voice EVF-1122D/94 is a high-power, two-way loudspeaker system for applications requiring high-quality sound reinforcement in a compact, lightweight package. It utilizes the DH7N high-output 3" titanium compression driver, coupled to a Constant Directivity 90° x 40° waveguide, and the DVX3121A 12" woofer developed using FEA optimization for very low distortion, high efficiency, and maximum intelligibility at high SPL. The trapezoidal enclosure is constructed of weather-resistant birch and coated with EVCoat.

• 12-inch arrayable two-way point-source loudspeaker
• Rotatable constant directivity waveguide
• 97 dB sensitivity, 131 dB maximum SPL
• System rating: 600 W continuous, 2400 W peak

Frequency response (-3 dB): 57 Hz - 18 kHz Frequency range (-10 dB): 49 Hz - 21 kHz Coverage (H x V): 90 x 40 degrees Recommended high-pass frequency: 65 Hz Axial sensitivity: 97 dB (1W/1m) Max. calculated SPL: 131 dB Power handling: 600 W continuous, 2400 W peak LF transducer: DVX3121A, 12 in (305mm) driver HF transducer: DH7N, 3 in (76mm) diaphragm compression driver Impedance: 8 Ohm nominal, 6.0 Ohm min. Enclosure: 13-ply weather-resistant birch with EVCoat Suspension: (22) M10 threaded points Dimensions (H x W x D): 30.26 in x 16.00 in x 16.27 in (768.6 x 406.3 x 413.3 mm) Net weight: 65.5 lb (29.7 kg) Shipping weight: 75.8 lb (34.4 kg) Color: White

EVF-1122D/94-WHT loudspeaker
EBK-M10-EVI eyebolt kit (4 forged eyebolts)
