Electro-Voice EVU-1082/95-WHT - 8" 2-Way Loudspeaker, White

The Electro-Voice EVU-1082/95 is a compact two-way loudspeaker system that can be used in a variety of applications where high quality sound reinforcement is required in an ultra-compact lightweight enclosure. The enclosure design utilizes asymmetric angles to maintain tight clearances to walls and ceilings while providing optimal coverage patterns, making it ideal to blend into surroundings. The EVU-1082/95 incorporates the ICT-1-8, a high-output 1.3" diaphragm titanium compression driver coupled to a Constant Directivity 90 x 50 degree rotatable waveguide. The EVU series is constructed of 9-ply hardwood plywood enclosures with six integral M8 suspension points, finished in textured paint.

• 1.3" (33 mm) diaphragm, pure titanium compression driver
• 8" (203 mm) LF transducer
• Coverage pattern: 90 x 50 degree Constant Directivity rotatable waveguide
• 95 dB sensitivity, 123 dB maximum SPL
• System rating: 175 W continuous, 700 W peak
• Universal U-bracket included
• Optional 70.7/100-V transformer accessory
• (6) M8 threaded suspension points

Frequency response (-3 dB): 110 Hz - 16 kHz Frequency range (-10 dB): 65 Hz - 20 kHz Coverage (H x V): 90 x 50 degrees Recommended high-pass frequency: 90 Hz Passive crossover frequency: 2300 Hz Axial sensitivity: 95 dB (1W/1m) Max. calculated SPL: 123 dB Power handling: 175 W continuous, 700 W peak Impedance: 8 Ohm nominal, 6.0 Ohm min. LF transducer: ICT-8-8, 8 in (203mm) driver HF transducer: ICT-1-8, 1.3 in (33mm) diaphragm compression driver Connectors: Single 4-pin 12 AWG Phoenix/Euroblock screw terminals Enclosure: 9-ply hardwood plywood with textured paint Grille: 18 GA steel with cloth Suspension: (6) M8 threaded points Dimensions (H x W x D): 9.73 in x 16.11 in x 9.34 in (247.2 x 409.1 x 237.2 mm) Net weight: 16.3 lb (7.4 kg) Shipping weight: 22.6 lb (10.2 kg) Color: White

EVU-1082/95-WHT loudspeaker
Universal U-bracket
