QSC KS118 - 18-inch 3600 Watt Active Subwoofer
- 18" inches active subwoofer
- 3600 W with a Class D amplifier module
- M20 fittings available for either horizontal or vertical position (included)
- Low-noise and effective cooling system
- Four low-noise, heavy-duty casters
QSC KS118 - 18-inch 3600 Watt Active Subwoofer
Product Details
Product Specifications
|
SPECIFICATIONS |
KS118 |
|
Configuration |
Direct Radiating |
|
LF Transducer |
18-inch (460 mm), Cone |
|
Frequency Response (-6 dB) |
41 Hz - 98 Hz |
|
Frequency Range (-10 dB) |
35 Hz - 111 Hz |
|
Nominal Coverage Angle |
Omni-directional or cardioid radiation modes (cardioid setup requires min. 2 units) |
|
Maximum Rated SPL1 |
136 dB @ 1 m (peak) |
|
Amplifier |
Class D |
|
3600W (peak) |
|
|
Cooling |
Low-noise, variable speed fan |
|
Controls |
Power On/Off |
|
Gain Control |
|
|
Rotary encoder |
|
|
2 x selection buttons |
|
|
Indicators |
2 x Power LED (front and rear) |
|
Input Signal LED |
|
|
Limiter active LED |
|
|
Connectors |
2 x locking XLR/F ¼ inch combo |
|
2 x XLR/M (Loop-thru Output) |
|
|
1 x locking IEC power connector |
|
|
AC Power Input |
Universal power supply 100 – 240 VAC, 50 – 60 Hz |
|
AC Power Consumption (⅛ power) |
100 VAC, 3.6 A / 120 VAC, 3.0 A / 240 VAC, 1.7 A |
|
Enclosure Details |
|
|
Enclosure |
18 mm birch plywood |
|
Color |
Black (RAL 9011) |
|
Grille |
16-gauge Black Powder Coated Steel |
|
Dimensions (HWD) inches |
25.2" × 20.5" × 30.9" |
|
Dimensions (HWD) mm |
640 mm x 520 mm x 785 mm |
|
Net Weight |
(including casters) 47 kg (104 lbs) |
|
Shipping Weight |
56.5 kg (124.5 lbs) |
|
Regulatory |
CE, WEEE, UL, China RoHS, RoHS II, FCC Class B |
|
Included Accessories |
4 x Low-Noise, Heavy Duty Casters |
|
Optional Accessories |
KS118-CVR Transport Cover, KS-LOC Lock-Out Cover |
|
SP-26 and SP-36 Loudspeaker Poles, SP-16X Extension Pole |
Product Features
The KS118 is a very high output active subwoofer producing impressive low frequencies for mobile entertainment, AV production, clubs and performance venues. Featuring an 18-inch direct radiating driver powered by a 3600 Watt Class D amplifier, the KS118 delivers high sound pressure levels with dynamic and musical sound reproduction of very low frequencies
On-board DSP optimizes and protects system performance as well as offers advanced capabilities such as the ability to array two units in a cardioid arrangement. Highly transportable, the rugged enclosure features comfortable handles and four low noise casters. An M20 threaded pole receptacle accepts a 35 mm pole for easy vertical deployment with full-range loudspeakers
Key Features:
- Very high output with impressive low-frequency performance
- 3600 Watt Class D amplifier module
- 18 inch (460 mm) long excursion direct radiating driver
- Omni-directional or cardioid radiation modes (cardioid setup requires min. 2 units)
- Selectable DEEP mode for extremely low-frequency extension
- Adjustable crossover and delay
- Scenes for commonly-used applications that can be saved/recalled
- Refined, professional and elegant appearance in any application
- Rugged painted wood enclosure for lasting durability
- Vertical or horizontal deployment (M20 threaded pole receiver for vertical setup)
- Four low-noise, heavy-duty casters
- Optional transport cover, temporary weather cover, KS-LOC security cover and 35 mm loudspeaker pole accessories available
- 6-Year Warranty with product registration
