ECLER WARM2 - Analogue Rotary Mixer Unit

Availability: Sold out. More coming soon. Pre-Order now.

Regular Price: $1,429.99

Special Price: $1,099.99

Qty:
+ -

Regular Price: $1,429.99

Special Price: $1,099.99

free shipping
Free Shipping
On Continental US Orders Over $100!




Overview

- 2+1 channels Analogue rotary mixer
- Classic 3-band isolator with 4th-order filters
- Balanced XLR and RCA master outputs
- Alps Blue Velvet potentiometers for smooth control
- Compact, aluminum build with wooden side panels


Details

WARM2 is a professional two-channel analogue rotary DJ mixer, designed and manufactured by ECLER in Barcelona. Featuring two phono/line channels and a micro/line channel, classic sharp filters, a 4th order Isolator and a narrow portable format, it will deliver a warm and crystal clear analogue sound.

Key Features:

  • 2+1 Mixing channels
  • 1 MICRO input
  • 2 PHONO inputs
  • 3 LINE inputs
  • Master Output (HOUSE) on XLR and RCA connectors
  • Booth Output on RCA connectors
  • 6.3mm Jack and 3.5mm mini-jack Headphone Monitor Outputs
  • 3 band full cut EQ for main channels and 2 band full cut EQ for MICRO/LINE channel
  • 3 bands isolator (300Hz and 4KHz, -∞/+12dB, 4th order 24dB/oct )
  • Maximum Output without distortions: 21dBV (23dBu)
  • Mechanized from a solid block of aluminum knob, without visible screw. Ecler Unique design
  • Alps Blue Velvet Potentiometers
  • FX Send control and Pre/Post fader selector
  • Screen-printed faceplate by selective anodizing
  • Wooden side panels included

WARM2 is the first Ecler rotary mixer inspired by The Warehouse in Chicago, a place where many consider the cradle of House Music back in 1977. This place ignited the spark that eventually became the House Music scene we love and admire today. Back in the days, Ecler was forging its own place among the Dj Mixer manufactures, while
Frankie Knuckles, the godfather of House Music and The Warehouse first musical director, was reconstructing the soul and disco existing songs, by changing the tempo and layering different bits of percussion over them. These alterations transformed the dancefloor forever.

Rotary mixers have an special feel, creating a smoother and subtler transitions. Legendary Djs like Joe Clausell, Louie Vega and more recently Floating Points or Motorcity Drum Ensemble are top class users of these particular devices. With WARM2, you’ll be able to get Ecler's design expertise at your fingertips, its unquestionable audio quality, and the “Alps Blue Velvet” potentiometers precision for the perfect mix. The 4th order inbuilt isolator, will definitely expand your performance possibilities by removing frequencies, infusing drama in an acapella track, enhancing musical riffs or creating a tremolo effect by rapidly twisting the knobs.

With a width of 18.5 centimeters, WARM2 is the narrowest rotary mixer on the market. Despite this, it includes interesting features such as: 3-band EQ + Trim, FX Send control and Pre/Post fader selector, and an excellent dynamic and headroom range. WARM2 provides the best analog sound for your dancefloor in a portable format.

specifications

Característica

Entrada/Salida

Especificación

Inputs Sensitivity nom/Impedance

LINE

0dBu/50Ω



MICRO

-40dBu/50Ω



PHONO

-50dBu/>1kΩ



FX RETURN

0dBu/>6kΩ

Outputs Level/Minimum Load

HOUSE (BAL)

0dBu/600Ω 1V* (+12dBu 4V)



HOUSE (UNBAL)

0dBu/2.2kΩ 1V* (+12dBu 4V)



BOOTH (UNBAL)

0dBu/2.2kΩ 1V* (+12dBu 4V)



REC

0dBu/10kΩ



HEADPHONES

200mΩ/200Ω THD 1%



FX SEND

0dBu/2.2kΩ

Frequency Response

LINE

10Hz-30kHz -1dB



MICRO

10Hz-25kHz -1dB



PHONO

RIAA ±0.5dB



FX RETURN

10Hz-50kHz -1dB

THD+N

LINE

<0.006%



MICRO

<0.9%



PHONO

<0.08%



FX RETURN

<0.005%

CMMR

MICRO

>70dB @ 1kHz

Signal Noise Ratio

LINE

>99dB



MICRO

>85dB



PHONO

>98dB



FX RETURN

>100dB

Max Undistorted Output Level

HOUSE (Electr.BAL)

21dBu (23dBu)



HOUSE (UNBAL)

21dBu (23dBu)



BOOTH (UNBAL)

21dBu (23dBu)

Trim control

INPUTS 1-2

± 15dB



INPUT 3

± 20dB

Tone control Inputs 1-2

BASS

+10/-30dB



MID

+10/-25dB



TREBLE

+10/-30dB

Tone control Input 3

BASS

± 15dB

what's included
  • ECLER WARM2
  • IEC Main Connector
  • First Steps Guide
  • Warranty card.
