Allen & Heath Xone:43 - 4 Channel Analogue DJ Mixer
- Created for DJs and electronic music purists
- 4+1 channel DJ mixer
- Offers the very best of analogue audio quality
- Includes the legendary Xone filter with resonance control
- 3 band EQ
- Crossfader with three switchable curve settings
- Easily replace or upgrade to a custom Innofader for ultimate crossfader performance
- Balanced XLR main outputs, independent booth and record outputs
Allen & Heath Xone:43 - 4 Channel Analogue DJ Mixer
Product Details
Product Specifications
| SPECIFICATIONS | |||
| Nom / max output levels | Main Mix | +4dBu | +27dBu |
| Booth | 0dBu | +22dBu | |
| X:FX Send | 0dBu | +20dBu | |
| Record Out | 0dBu | +20dBu | |
| Internal headroom | Channels +20dB | ||
| Frequency response | +/-0.5dB 20Hz - 20kHz | ||
| Distortion | < 0.05% THD+noise @1kHz Crosstalk | ||
| Crosstalk | < -83dB inter-channel | ||
| Residual noise | Mix 1 | -89dBu | |
| Booth | -93dBu | ||
| X:FX | -77dBu | ||
| Rec | -92dBu | ||
| Mix noise | Mix 1 | -82dBu | |
| Booth | -84dBu | ||
| X:FX | -77dBu | ||
| Channel meters | Peak reading 9 LED -20dB to +10dB | ||
| Main meters | Peak reading 9 LED -20dB to +10dB | ||
| Mic EQ | 2-Band +/-12dB | ||
| Channel EQ | 3-Band +6dB / total kill | ||
| Channel fader | 45mm stereo VCA, < -85dB shutoff | ||
| Crossfader | 45mm stereo VCA - replaceable | ||
| Filters | Stereo VCF, analogue | ||
| Consumption | 30W max | ||
| DIMENSIONS AND WEIGHTS | |||
| Width | 320 mm | ||
| Height | 110mm | ||
| Depth | 370mm | ||
| Weight | 5.1 kg | ||
Product Features
4 CHANNEL ANALOGUE DJ MIXER
Created for DJs and electronic music purists, Xone:43 is a 4+1 channel DJ mixer that offers the very best of analogue audio quality, including the legendary Xone filter with resonance control, 3 band EQ, crossfader with three curve settings and X:FX for send/return to your favourite FX unit.
The crossfader has three switchable curve settings for blending or scratching styles and can be easily replaced or upgraded to a custom Innofader for ultimate crossfader performance.
With balanced XLR main outputs, independent booth and record outputs, Xone:43 excels in the club and in high end personal DJ setups.
FEATURES
- 4 channels with phono/line inputs
- VCF Filter system – low-pass, high-pass and band-pass filters plus frequency and resonance controls
- 3-band EQ
- External FX loop (Send/Return) system with dry/wet control per channel
- Mic input on balanced XLR, with 2-band EQ
- Balanced main mix out on XLR
- Independent booth out
- Record out
- 3.5mm and 1/4″ headphone outputs
- Touring grade build quality
- Super smooth VCA channel faders
- User changeable crossfader
- Innofader compatible
- Crossfader curve switch
- 20dB pro standard headroom
- 9-segment signal level monitoring
