Electro-Voice EVF-1152S/96-WHT - 15” 2-Way Loudspeaker with 90 x 60 Coverage, EVCoat White

The Electro-Voice EVF-1152S/96 is a high power, 2-way loudspeaker system that can be used in a variety of applications where high quality sound reinforcement is required in a compact, lightweight package. The EVF-1152S/96 utilizes the ND2B, a high output 2” titanium compression driver, coupled to a Constant Directivity 90° x 60° waveguide. The SMX2151 15” woofer used FEA optimization for motor, suspension, and electrical design for very low distortion, high efficiency, and maximum intelligibility at high SPL levels. The trapezoidal enclosure is constructed out of weather resistant birch, and coated with EVCoat for maximum protection from the elements.

• 15-inch arrayable two-way point-source loudspeaker
• Rotatable constant directivity waveguide
• 101 dB sensitivity, 134 dB maximum SPL
• System rating: 500 W continuous, 2000 W peak

Frequency response (-3 dB): 70 Hz - 14 kHz Frequency range (-10 dB): 41 Hz - 18 kHz Recommended hi-pass frequency: 45 Hz Axial sensitivity: 101 dB (1W/1m) Max. calculated SPL: 134 dB Coverage (H x V): 90 x 60 degrees Power handling: 500 W continuous, 2000 W peak LF transducer: SMX2151, 15 in (381 mm) driver HF transducer: ND2B, 2 in (51 mm) diaphragm compression driver Crossover frequency: 1450 Hz Nominal impedance: 8 Ohm Minimum impedance: 6.0 Ohm Connectors: (2) 4-contact 10 AWG Phoenix/Euroblock screw terminal Enclosure material: 13-ply weather resistant birch Grille: 16 GA Galvanneal, powdercoat, rotatable logo Suspension: (22) M10 threaded points Dimensions (H x W x D): 30.26 in x 18.50 in x 18.37 in (768.6 x 469.8 x 466.6 mm) Net weight: 70.9 lb (32.1 kg) Shipping weight: 81.2 lb (36.8 kg) Color: White

EVF-1152S/96-WHT loudspeaker
EBK-M10-EVI eyebolt kit (4 forged eyebolts)
