Product Features

The HALO Q4 WASH was designed for production companies, venues, mobile entertainers, and lighting professionals who need a high-output LED wash fixture capable of delivering vibrant color, smooth dimming, and dynamic visual effects. Combining a powerful RGBW LED engine with an integrated ring effect and professional control features, the HALO Q4 WASH provides exceptional performance for stages, concerts, houses of worship, clubs, and live event productions.

Powered by a **180W RGBW LED engine (90 × 2W LEDs)**, the HALO Q4 WASH delivers rich color mixing, adjustable white light from **2800K to 8000K**, and smooth, even coverage across a **25° wash beam angle**. Its integrated **dynamic ring effect**, **25Hz electronic strobe**, **16 preset color programs**, **15 built-in auto programs**, and **15 advanced sound-active modes** provide a wide range of creative effects, while **32-bit dimming** ensures exceptionally smooth fades for professional productions. Featuring multiple DMX personalities, 3-pin DMX512 control, and powerCON In/Out for convenient power linking, the HALO Q4 WASH offers intuitive operation and dependable performance for both programmed shows and standalone applications.

Whether washing stages with vibrant color, highlighting performers, enhancing live productions, or creating dynamic visual effects for concerts, houses of worship, and special events, the JMAZ HALO Q4 WASH delivers powerful output, smooth dimming performance, and professional wash lighting for today’s demanding environments.

Product Specifications

Light Source

90 x 2W RGBW LEDs

Color System

RGBW LEDs



CCT: 2800K – 8000K

Optics

Beam Angle: 25°

Dynamic Effect

16 Preset Color Programs



15 Auto Bulit In Programs



15 Advanced Sound Active Mode



Dynamic Ring Effect



Wash Effect



Strobe 25Hz Effect



32-bit Dimming

Control

Protocols: 3-Pin In/Out DMX512



Personalities: 4 Modes 6/9/36/41

Electronics

Dimmer: 0-100% Linear Dimmer

Body

ABS Die-Cast Plastic w/ Aluminum Structure

Physical

Cooling: Fan



3-Pin In/Out DMX512



powerCON In/Out

Electrical

Max Power Consumption: 180W



Input Voltage: AC 100-240V, 50HZ/60HZ

Box Content

1 x User Manual



1 x 3-pin DMX Cable



1 x powerCON Cable

Item Dimensions & Weight

Dimensions: 16.1″ x 15″ x 7.5″



Weight: 10.5 lbs

Warranty

2 Years

What's included

- JMAZ HALO Q4 WASH
- User Manual
- 3-pin DMX Cable
- powerCON Cable
