The JMAZ Centipede 3SIXTY B4 is a compact, high-impact RGBW moving head bar designed to deliver powerful lighting effects in a streamlined format. Featuring four 60W RGBW LEDs and 120 RGB SMD LED ring lights, each head offers 360° infinite pan/tilt and independent pixel control for endless creative possibilities. Built-in color and movement macros—with foreground and background control—make programming fast and efficient. With a tight 3.5° beam angle, 16-bit color mixing, and a tunable CTO range of 2500K to 8000K, the B4 excels in both beam intensity and color precision. Ideal for DJs, clubs, concerts, and installations, it runs in four DMX personality modes (25/47/69/90 channels) and supports 5-pin DMX512, Art-Net, RDM, sACN, and Kling-Net protocols. TRUE1 IN/OUT connections ensure secure, professional-grade power delivery. The fixture includes a TRUE1 power cable, 5-pin DMX cable, two omega brackets, two safety cables, and a manual. CE, cETL, FCC, and RoHS certified for global compliance.
Light Source |
240W (4 x 60W) RGBW LED |
|
Ring Effect: 24W (120 x 0.2W) RGB SMD LED |
|
CTO: 2500K – 8000K |
Color System |
RGBW LED |
Optics |
Beam Angle: 3.5° |
|
16 bit RGBW Color Mixing |
Dynamic Effect |
Individual Head 360° Infinite Pan/Tilt Control |
|
Individual Head Pixel Control |
|
Individual Dynamic Ring Color And Effect Macros |
|
Built-In Virtual Colors And Movement Macros w/ Foreground and Background Color Control |
Control |
Personalities: 4 Modes 25/47/69/90 |
|
Protocol: 5-Pin DMX512, Art-Net, RDM, sACN, Kling-Net |
Electronics |
Power Connection: TRUE1 In/Out |
Physical |
TRUE1 Power Cable |
|
5-Pin DMX Cable |
|
2 Omega Bracket |
|
2 Safety Cable |
|
Manual |
Electrical |
CE, cETL, FCC, Rohs Certified |
Item Dimensions & Weight |
Dimensions: 31″ x 6.6″ x 10.5″ |
|
Weight: 33.95 lbs |
- JMAZ PROFESSIONAL CENTIPEDE 3SIXTY B4
- 1 x TRUE1 Power cable
- 1 x 5-pin DMX Cable
- 1 x User Manual
- 2 x Omega Brackets
- 2 x Safety Cable
